Leapers 30mm QR Picatinny Cantilever Mount

  • Item Number: AIR32234Q
  • /
  • View More Items by Leapers
  • /
  • Condition: NEW
Leapers 30mm QR Picatinny Cantilever Mount
  • $67.42
Available as a Marketplace Deal.
Learn more

Product Description

The UTG ACCU-SYNC AIR32234Q is a quick-detach 30mm cantilever scope mount designed for Picatinny rails. Precision CNC machined from 6061-T6 aircraft-grade aluminum, it features a high-profile 0.87-inch saddle height, 34mm forward offset, integral recoil stops, and a lightweight design. It is rated for calibers up to .338 Lapua Magnum.

Product Features

  • 30mm Scope Compatibility: Designed for optics with 30mm main tubes.
  • Quick-Detach Design: Allows the mount to be quickly attached and removed from Picatinny rails.
  • 34mm Cantilever Offset: Positions the scope 34mm forward for improved eye relief and proper optic placement.
  • High-Profile Configuration: Provides a 0.87-inch saddle height.
  • Aircraft-Grade Aluminum: Precision CNC machined from lightweight 6061-T6 aluminum.
  • Integral Recoil Stops: Square-shaped recoil stops help maintain a secure mounting position.
  • Lightening Cuts: Strategically machined cuts reduce weight without compromising structural integrity.
  • Progressive Machining: Provides precise inner-ring dimensions for proper scope alignment.
  • Radiused Edges: Helps reduce snagging and protects surrounding gear.
  • Locking Torx Screws: Provides secure scope retention and mounting.
  • Heavy-Caliber Rated: Rated for use up to .338 Lapua Magnum.
  • Anodized Finish: Provides a durable, corrosion-resistant surface.

Product Specifications

  • Product Type: Quick-Detach Cantilever Scope Mount
  • Model: ACCU-SYNC
  • Part Number: AIR32234Q
  • Scope Tube Diameter: 30mm
  • Mounting Interface: Picatinny Rail
  • Mount Style: Cantilever
  • Height Profile: High
  • Saddle Height: 0.87 in. / 22mm
  • Center Height: 1.38 in. / 35mm
  • Cantilever Offset: 1.34 in. / 34mm
  • Integral Base Length: 3.94 in. / 100mm
  • Overall Length: 5.28 in. / 134mm
  • Ring Distance: 1.73 in. / 44mm
  • Ring Width: 0.98 in. / 25mm
  • Maximum Objective Diameter: 2.87 in. / 73mm
  • Weight: 5.9 oz. / 167g
  • Material: 6061-T6 Aluminum
  • Finish: Anodized
  • Quick-Detach: Yes
  • Caliber Rating: .338 Lapua Magnum
  • Optic-to-Mount Torque: 25 in-lbs
  • Mount-to-Rail Torque: 35 in-lbs
  • Color: Black
